1 / 3SKU: DRP-CYL
Thick-wall round drip pipe with inline emitters for permanent installations in orchards and vineyards.
Material
PE, HDPE
Size Range
16mm / 20mm
Pressure
0.10 - 0.35 MPa
Standards
ISO9261
INQUIRY FOR:
Inline Drip Pipe
| Parameter | Value |
|---|---|
| Wall Thickness | 0.9 / 1.0 / 1.2mm |
| Dripper Spacing | 20 / 30 / 40 / 50 / 75 / 100cm |
| Flow Rate | 1.2 / 1.6 / 2.0 / 4.0L/h |
| Operating Pressure | 0.10 - 0.35MPa |
| Diameter | 16 / 20mm |
| Roll Length | 100 / 200 / 400m |
Walk into almost any commercial farm and you'll find inline drip pipe running along the rows. It's not glamorous equipment, but it does most of the work. Ours is black polyethylene — thick-walled, lightweight, and built to handle real field conditions without cracking under pressure or UV exposure. The thicker wall tolerates higher flow rates than standard drip pipe, and the adjustable flow rate makes it usable across crops with very different water needs.
An internal filtering mechanism at each emitter reduces clogging from sediment and debris — important on long runs where a single blocked emitter affects everything downstream.
The long flow channel runs water at high pressure, generating turbulent flow inside the pipe. That turbulence flushes particles through before they settle and block an emitter.
Dripper spacing is set at order — choose the interval that matches your crop's row spacing and root spread rather than working around a fixed spec.
Available in three diameters. Wall thickness, flow rate, and spacing can be selected to match your system's pressure and crop requirements.
| Diameter (mm) | Wall Thickness (mm) | Dripper Flow Rate (L/H) | Spacing (mm) | Working Pressure (MPa) | Package |
|---|---|---|---|---|---|
| 20 | 1.0 | 4, 6 | 200 / 250 / 300 / 400 / 500 | 0.05 – 0.3 | 500 m / roll |
| 16 | 0.6 / 0.8 / 1.0 | 1, 2, 4, 6 | — | — | — |
| 12 | 0.6 / 0.8 / 1.0 | 2, 4 | — | — | — |
